DZ-1000QF Pneumatic Opertion Roller Type Vacuum Se

Automatic continuous type vacuum packaging machine continuously operates through the rotation of the conveyor belt and applies to the product packaging of large productive enterprises. Depending on the size of the contents and different requirements for production effciency. one or two seals may be set within one chamber in order to improve working efficiency. The bottom plates of the two vacuum chambers of the series of machines are driven in two modes,pneumatic driving and mechanical driving. At the same time. we may custom-tailor vacuum chambers in sizes suitable for the contents for customers so the machine can operate in optimum state. The efficiency of vacuum packaging work depends on exhaust port of the vacuum pump of the machine, The machine is standard with a vacuum pump as listed in the table. A vacuum pump with higher capacity is available upon customer's request. Technical Characters: 1.Programmable Control System: SIEMENS PLC, it could be programed by customers' requirement 2.Vacuum Pump: strict quality examination systom insured the heat of vacuum packaing machine runned smoothly, (Different brand and exhaust ports of vacuum pump could be configured according to customers specifications) 3.Main structure's material: Main structure’s material of vacuum packaging machine is 304 stainless steel, which insures the beautiful appearance and antisepticise under serious cauterization circumstance 4."V" type lid gasket: The "V" type lid gasket is made from high density material which prolong the using life and wearable in the daily usage, it's also reduced the replacement time and production cost 5.Heavy moving wheel (with brake): The heavy moving wheel with high bearing capability, which makes customer moving easily 6.Adjustable worktable: Adjustable worktable is designed for providing more convenience for operator usage, operator could adjust the height of worktable according to packing production characters and operator’s stature 7.Overturnable vacuum lid: Overturnable vacuum lid is designed for making maintain persion easily maintain 8.Up-down moving type vacuum chamber bottom board prolong the working life of conveying belt 9.Because of adopting pneumatic construction and up-setted electric appliance, the size of machine became much more smaller, saving space and easily for cleaning Technology SpecificationsModelDZ-1000 QFMachine Dimensions (mm)1520×1400×1260Chamber Dimensions (mm)420×1080×160Sealer Dimensions (mm)1000×8×2Pump Capacity (m3/h)100Power Consumption (kw)3Voltage (V)220/380/415Frequency (Hz)50/60Production Cycle (times/min)2-3G.W (kg)600N.W (kg)550Shipping Dimensions (mm)1640×1520×1480
